Cavitation Apparatus

Product Description

Cavitation Apparatus

The present set-up consists of a  test  section  made  of  Acrylic  having  conversion  and diversion  section.  Pressure tapings  at  appropriate position  are  provided.  This test section  is  having one control valve at upstream side to regulate the water flow rate. Two pressure gauges are connected to these taping which give  the  pressure  readout  at  the  time  of  flow passing through this test section.  Present set-up is self-contained water re-circulating unit, provided with a sump tank, centrifugal pump etc. Water is pumped by  means of  centrifugal  pump  and  passing through  the  test  section,  it  returns  back  to  the  sump which make the system re-circulating type.

Specification:

Floor Area Required: 1.5 m (L) x 1 m. (W)

Test Section: Material Acrylic/Poly Carbonate

Pressure Gauge: 0-5 kg/cm2

Vacuum Gauge: 0-760 mmHg

Water Circulation: Pump Crompton make

Flow Measurement: Measuring Tank (Capacity: 50 liters) & Electronic Stop Watch.

Sump Tank: Capacity: 60 liters

Control Panel would comprise of :

Standard make On/Off Switch, Mains Indicator, etc.

Apparatus Tanks would be made of Stainless Steel.

Apparatus would be capable of finding cavitation phenomena also it would be able to compare the theoretical and actual pressures at cavitation condition.
